Complete: Spur Carbon GX

The All-Country Bike
Effortlessly explore, seek, and pursue the mountain in ways you never imagined.

The Spur provides a sense of connection to the bike as if it were an extension to your body. Fast and efficient with an anti-gravity feel and laser-pointer precision that begs you to climb more, go farther, and descend anything you may encounter along the way. You'll instantly appreciate the free speed you're awarded while accelerating where you're usually accustomed to pedaling. Don't judge a book by its cover though, with all these lightweight and uphill oriented character traits the Spur requires no adjustment to descend like you're used to, you might actually go faster.

GIDDYUP SUSPENSION DESIGN

We want to make it as easy as possible to experience great rear suspension performance. The GiddyUp suspension system is designed to behave intuitively across a broad range of setup. Because, we get it, sometimes you just want to grab your bike and GiddyUp, without checking your setup. When you do, it will always feel good.

With nearly 30% of progression and a consistent linear rate of change, the Spur has an excellent balance of support and small bump sensitivity. Anti-squat is tuned to enhance pedaling performance and acceleration but doesn't get in the way of the suspension working when it's needed.

The GiddyUp suspension, featuring a one-piece flex stay rear triangle, is tuned to work correctly with inline style rear shocks and designed to provide a balanced feel with 120mm travel forks. Riders are able to add or remove volume spacers in the rear shock to suit their individual riding style and there is plenty of bottom out control for when things get rowdy. The Spur has 120mm of rear wheel travel when used with the supplied 190mm x 45mm stroke shock. It is also possible to install a shorter, 190mm x 37.5mm stroke shock, to reduce the rear wheel travel to 100mm if you are after a shorter travel experience.

A wide usable sag range of 25 - 35% allows the rider to tune the feel of the bike; from firm and snappy, to more supple and active. Wherever you end up, you can focus on the trail without remotes, levers or knobs. Just grab your bike and GiddyUp.

Frame Specifications

REAR TRAVEL:	120mm (Compatible with 100mm)
FRONT TRAVEL:	120mm
WHEEL SIZE:	29"
SIZES:	SM, MD, LG, XL
COLORS:	Aqua, Raw, Deep Sea Green, Black Powder
FRAME BEARINGS:	2x 6903, 4x 6901
FORK AXLE TO CROWN:	533mm (Includes headset)
FORK OFFSET:	44mm
REAR SHOCK SIZE:	190mm x 45mm (Compatible with 190mm x 37.5mm)
SHOCK HARDWARE:	30mm x 8mm Top / 25mm x 8mm Bottom
HEADSET (TOP):	44mm Zero Stack
HEADSET (BOTTOM):	56mm Zero Stack
BB SHELL:	73mm BSA Threaded
CHAINLINE:	52mm
REAR BRAKE MOUNT:	160mm Post Mount, Max Rotor Size 180mm
REAR AXLE:	Syntace X12 148 (Boost), 1.0mm Thread Pitch
ISCG TABS:	ISCG05 (Top/Front 2 mounts only)
SEATPOST DIAMETER:	31.6mm
SEAT CLAMP:	37.0mm
MAX SEATPOST INSERTION:	Small 250mm | Medium 280mm | Large 330mm | XL 330mm
MAX CHAINRING SIZE:	36T Standard Single Ring
MAX TIRE SIZE:	29 x 2.4
REAR SHOCK SAG:	120mm (45mm) = 12-15mm (27-33%) 100mm (37.5mm) = 10-12mm (27-33%)
